Отвод 90°
| SDR 17 (PN10) | SDR 11 (PN16) | ||
| d(mm) | z(mm) | L(mm) | e(mm) |
| 20 | 75 | 52 | 3 |
| 25 | 80 | 52 | 3 |
| 32 | 85 | 54 | 3 |
| 40 | 95 | 57 | 3.7 |
| 50 | 105 | 63 | 4.6 |
| 63 | 115 | 65 | 5.8 |
| 75 | 130 | 72 | 6.8 |
| 90 | 150 | 81 | 8.2 |
| 110 | 165 | 86 | 10 |
| 125 | 180 | 93 | 11.4 |
| 140 | 202 | 92 | 12.7 |
| 160 | 210 | 103 | 14.6 |
| 180 | 232 | 107 | 16.4 |
| 200 | 253 | 117 | 18.2 |
| 225 | 270 | 122 | 20.5 |
| 250 | 292 | 130 | 22.7 |
| 280 | 320 | 139 | 25.4 |
| 315 | 365 | 150 | 28.6 |
| d(mm) | L(mm) | R(mm) | z(mm) |
| 90 | |||
| 110 | 150 | ||
| 125 | 150 | 188 | 388 |
| 140 | 150 | 210 | 360 |
| 160 | 150 | 240 | 390 |
| 180 | 150 | 270 | 420 |
| 200 | 150 | 300 | 450 |
| 225 | 150 | 338 | 488 |
| 250 | 250 | 375 | 625 |
| 280 | 250 | 420 | 670 |
| 315 | 300 | 473 | 778 |
| 355 | 300 | 533 | 833 |
| 400 | 300 | 600 | 900 |
| 450 | 300 | 675 | 975 |
| 500 | 350 | 750 | 1100 |
| 560 | 350 | 840 | 1190 |
| 630 | 355 | 945 | 1295 |
| 710 | 360 | 1065 | 1415 |
| 800 | 400 | 1200 | 1550 |
| 900 | 450 | 1350 | 1625 |
| 1000 | 500 | 1500 | 1735 |
